ZENER DIODE CH. APPARATUS (4 METER) DIGITAL

Price 5200 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ZENER DIODE CH. APPARATUS (4 METER) DIGITAL Specification

Power Source
AC Mains 220 V / 50 Hz

Frequency
50 Hz

Model No
EI-507ZDCD-4M-DGTL

Accuracy
0.5% FSD

Capacity
4 Meter (Voltmeter and Ammeter range)

Temperature Range
Ambient

Voltage
0-30V adjustable

Automation Grade
Manual

Feature
Inbuilt Zener diode, inbuilt meters, easy to operate, overcurrent protection

Measurement Range
0-4 mA (Ammeter), 0-4 V (Voltmeter)

Core Components
Digital meters, Zener Diode, Variable Power Supply, Switches, Sockets

Equipment Materials
ABS Body, High-Quality PCB, Metal Panel

Type
Zener Diode Characteristic Apparatus

Usage
Educational laboratory for electronic experiments

Display Type
Digital

Dimension (L*W*H)
340 x 230 x 115 mm

Weight
Approx. 2.2 kg

Protection
Fuse and current limiter

Operating Environment
Indoor, non-condensing

Input Supply Voltage
220V AC, 50Hz

Finish
Powder-coated steel panel

Compliance
Meets standard educational lab requirements

Application
Study of VI characteristics of Zener diode (forward & reverse bias)

Zener Diode Specification
Inbuilt, 6.2V, 400mW

Front Panel
Clearly marked circuit schematic with tested points

External Connections
Banana Sockets for circuit configuration

Number of Displays
2 (Digital Voltmeter and Ammeter)

ZENER DIODE CH. APPARATUS (4 METER) DIGITAL Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About ZENER DIODE CH. APPARATUS (4 METER) DIGITAL

Pick Yours - the ZENER DIODE CH. APPARATUS (4 METER) DIGITAL, a first-rate educational tool for studying the prodigious VI characteristics of Zener diodes in both forward and reverse bias. Popular among schools and colleges, this supreme apparatus is your last chance to equip your lab with precision. Featuring two digital displays (voltmeter and ammeter), inbuilt 6.2V/400mW Zener diode, and a robust, powder-coated panel, it ensures safe and reliable operation. Intuitive banana sockets simplify external connections, and overcurrent protection guarantees durability. Ideal for hands-on electronic experiments.

Versatile Application for Electronic Learning

This supreme apparatus is tailored for indoor educational laboratories and supports a wide range of application media-internal circuit testing, practical demonstrations, and instruction modules. The standard application method involves connecting the ZENER DIODE CH. APPARATUS to AC mains and configuring external circuits using the banana sockets. Its primary function is to allow students and educators to analyze the VI characteristics of Zener diodes, making it invaluable for experiments and electronic theory validation.

Sample Access, Order Handling, and Certifications

Samples of the ZENER DIODE CH. APPARATUS (4 METER) DIGITAL can be handed over upon request for evaluation. Order processing time is prompt, ensuring timely delivery right from confirmation to shipment. The asking price is available upon inquiry and depends on the quantity and customization. Each unit meets standard educational certifications, affirming its quality and reliability as a first-rate teaching instrument for Indian academic and technical environments.
